GB/T700 GB/T1591 Carbon Steel Plate

The equivalent material of GB/T700 Q275 carbon steel and low alloy steel plate is S275JR steel plate. S275JR steel plate is a general-purpose carbon structural steel. This steel is similar to the steels listed in China GB/T700 and GB/T1591. It is also a carbon structural steel and low alloy structural steel used in engineering steel and structural steel, which is usually not heat treated. GB/T1591 steel plate is a Chinese standardized low alloy medium tensile strength steel plate produced by hot rolling process. GB/T1591 steel plate has a variety of manufacturing purposes.

A202 Pressure Vessel Steel Plate

ASTM A202 grade is divided into: A, B, boiler vessel plate is mainly used for welding boilers and other pressure vessels. There are two grades of ASTM A202 boiler vessel steel: Grade A and Grade B. The thickness of ASTM A202 boiler vessel plates is limited to 2in, I .e. 50mm.

A204 Pressure Vessel Steel Plate

ASTM A204 boiler vessel plate is molybdenum alloy steel plate, mainly suitable for welding boilers and high temperature pressure vessels. According to the molybdenum content, ASTM A204 boiler container plate is divided into 3 grades: A, B, C. The thickness of ASTM A204 boiler vessel plates is limited only by the ability of the chemical composition to meet the specified mechanical property requirements.

A533 Pressure Vessel Steel Plate

ASTM A533 Boiler vessel plates are manganese-molybdenum and manganese-molybdenum-nickel alloy steel plates suitable for welding pressure vessels. Often with quenching and tempering heat treatment, that is, quenching and tempering state supply. ASTM A533 boiler vessel steel is available in five different strength grades: Class A, Class B, Class C, Class D, and Class E. There are three levels of each category: level 1, level 2 and level 3.

JIS G3103 P296GH/P355GH/P235GH Pressure Vessel Steel Plate

JIS G3103 Boiler Container Plate is a hot-rolled plate of carbon steel and molybdenum alloy steel for Chinese and high temperature boilers and pressure vessels. The main grades of JIS G3103 boiler vessel steel are: SB410, SB450, SB480,SB450M and SB480M.

A588 Carbon Steel Plate

ASTM A588 steel includes Class A, Class B, Class C, and Class K. The ASTM A588 steel specification is based on the standard specification for high-strength low-alloy structural steel with a lower yield point of up to 50ksi for applications requiring high strength and corrosion resistance.

A36/Q235/S235JR Carbon Steel Plate

A36 is a low-carbon steel containing trace amounts of manganese, phosphorus, sulfur, silicon and other elements such as copper. A36 has good weldability and high yield strength, and is the structural steel plate specified by the engineer. ASTM A36 steel plate is often manufactured into a variety of structural steel parts. This grade is used for welded, bolted or riveted construction of bridges and buildings, as well as for general structural purposes. Due to its low yield point, A36 carbon plate can be used to design lighter weight structures and equipment, and provide good weldability. Construction, energy, heavy equipment, transportation, infrastructure and mining are the industries where A36 panels are commonly used.

A572/S355JR Carbon Steel Plate

A572 grades are divided into: 42, 50, 60, 65. The steel plate is light in weight, but has good strength, ductility and workability, making it an ideal choice for structural applications. These characteristics make the A572 relatively simple to shape into different structures, while maintaining the ability to withstand large stresses and loads.
